Engine

• 3 cylinder water-cooled 25hp Kohler diesel engine.

• Electric starter with alternator and other necessary electric gadgets such as volt meter, temperature meter, oil pressure meter and Odometer

• 3 cylinder water-cooled Perkins / Yanmar diesel engine.

• Electric starter with alternator and necessary electric gadgets such as volt meter, temperature meter, oil pressure meter and Odometer.

• 4 cylinder water-cooled Yanmar diesel engine.

• Electric starter with alternator and necessary electric gadgets such as volt meter, temperature meter, oil pressure meter and Odometer.

Drive System

• Variable Hydrostatic system -special technology for road marking machines from Italy.

• Heavy-duty hydraulic motor

• Driving speed 0-15km/h

• Marking speed 0-7km/h (for spray application only)

• Variable Hydrostatic system -special technology for road marking machines from Italy. (from the same supplier for Hofmann -Germany).

• Heavy-duty hydraulic motor

• Driving speed 0-18km/h

• Marking speed 0-10km/h (for spray application only)

• Variable Hydrostatic system -special technology for road marking machines (from the same supplier for Hofmann -Germany).

• Heavy-duty hydraulic motor

• Driving speed 0-15km/h

• Marking speed 0-5km/h (for spray application only)

Air Compressor

• FNA piston air compressor from Italy

• 1500 lit/m air delivery at 10 bar working pressure

• FNA piston air compressor from Italy

• 2500 lit/m air delivery at 10 bar working pressure

• FNA piston air compressor from Italy

• 2500 lit/m air delivery at 10 bar working pressure

Paint Tank

• 80 litres capacity twin paint tank complete with hydraulic stirrer

• Fitted with pressure gauge and air release valve

• Pressurized stainless steel tank

• 100 litres capacity paint tank complete with hydraulic stirrer

• Fitted with pressure gauge and air release valve

• Tank is made of stainless-steel plate

• 250 litres capacity paint tank complete with hydraulic stirrer

• Fitted with pressure gauge and air release valve

• The tank is made of stainless-steel plates

Machine Chassis

• Heavy-duty chassis made of mild steel channels

• Designed to withstand impact during operation on rough and tough road and airport surfaces

• Heavy-duty chassis made of special mild steel channels

• Designed to withstand impact during operation on rough and tough road surfaces, especially in the Middle East and Africa

• Heavy-duty chassis made of special mild steel channels

• Designed to withstand impact during operation on rough and tough road surfaces, especially in the Middle East and Africa

Spray Gun

• Model 84 Kamber: Cold paint gun from Switzerland. World first and the best spray gun manufacturer and supplier to all road marking machine fabricators worldwide

• Interchangeable material nozzle sizes 3.5 to 6mm according to the marking line

• Model 84 Kamber: Cold paint gun from Switzerland. World first and the best spray gun manufacturer and supplier to all road marking machine fabricators worldwide

• Interchangeable material nozzle sizes 3.5 to 6mm according to the marking line

• Model 84 Kamber: Cold paint gun from Switzerland. World's best spray gun Manufacturer and supplier to all road marking machine OEMs in the world

• Interchangeable material nozzle sizes 3.5 to 6mm according to the marking line

Glass Bead Guns

• Model PH84 Kamber: Special Glass Bead Spray Gun from Switzerland

• World-class glass bead spray gun with changeable nozzles

• Specially designed for spraying beads accurately and precise spreading

• 100kg capacity glass bead container- pressurized with both side outlets

• Model PH84 Kamber: Special Glass Bead Spray Gun from Switzerland

• World-class glass bead spray gun with changeable nozzles

• Specially designed for spraying beads accurately and precise spreading

• 100kg capacity glass bead container- pressurized with both side outlets

• Model PH84 Kamber: Special Glass Bead Spray Gun from Switzerland

• World-class glass bead spray gun with changeable nozzles

• Specially designed for spraying beads accurately and precise spreading

• 100kg capacity glass bead container- pressurized with both side outlets

Wheels

• Two special wheels in the front axle for steering and two wheels in the rear attached to hydraulic motors.

• Two special wheels in the front axle for steering and two wheels in the rear attached to hydraulic motors, attached to the parking brake.

• Two special wheels in the front axle for steering and two in the rear attached to hydraulic motors.

Computer

• Skip line device to control the paint spray gun and glass bead spray gun according to marking pattern and skip line gap.

• It works automatically according to the machine speed with encoder reading.

• Skip line device to control the paint spray gun and glass bead spray gun according to marking pattern and skip line gap.

• It works automatically according to the machine speed with encoder reading.

• Skip Line device to control the paint spray gun and glass bead spray gun according to marking pattern and dotted line gap.

• It works automatically according to the machine speed with encoder reading.

Steering

• Heavy-duty power-assisted (hydraulic) steering system for a firm operation.

• Heavy-duty power-assisted (hydraulic) steering system for firm operation.

• Heavy-duty power-assisted (hydraulic) steering system for firm operation.

Pneumatics

• World standard pneumatic accessories attached with full specification.

• Combination of Cammozi (Italy) and Janatics (Japan)

• Designed with auto-release valves and safety protection valves.

• Complete with water filter, lubricator, and flow regulators.

• 10 bar working pressure.

• World standard pneumatic accessories attached with full specification.

• Combination of Cammozi (Italy) and Janatics (Japan)

• Designed with auto-release valves and safety protection valves.

• Complete with water filter, lubricator, and flow regulators.

• 10 bar working pressure.

• World standard pneumatic accessories attached with full specification.

• Combination of Cammozi (Italy) and Janatics (Japan)

• Designed with auto-release valves and safety protection valves.

• Complete with water filter, lubricator, and flow regulators.

• 10 bar working pressure.

DC Electric

• 12V/55Amps DC electric circuit with emergency button complete with other important electrical components according to the road safety standard

• Signals lights, parking lights, working lights, horns, revolving lights, sport lights, safety meters, battery protectors and other necessary gadgets.

• 12V/65Amps DC electric circuit with emergency button complete with other important electrical components according to the road safety standard.

• Signals lights, parking lights, working lights, horns, revolving lights, sport lights, safety meters, battery protectors and other necessary gadgets.

• 12V/75Amps DC electric circuit with emergency button complete with other important electrical components according to the road safety standard.

• Signals lights, parking lights, working lights, horns, revolving lights, sport lights, safety meters, battery protectors and other necessary gadgets.

Hydraulic

• Twin Hydraulic tandem pump attached to the axial piston pump. Two for the paint tank stirrer systems.

• Complete hydraulic power pack. 60-litre hydraulic tank with all accessories.

• Standard suction and return filters, hydraulic oil cooling system with 12V fan.

• Twin Hydraulic tandem pump attached to the axial piston pump. Two for the paint tank stirrer systems.

• Complete hydraulic power pack. 60-litre hydraulic tank with all accessories.

• Standard suction and return filters, hydraulic oil cooling system with 12V fan.

• Hydraulic gear pump attached to the axial piston pump.

• Complete hydraulic power pack. 60-litre hydraulic tank with all accessories.

• Standard suction and return filters, hydraulic oil cooling system with 12V fan.

Dimensions

• Height: 2500MM (2.5M)

• Width: 1800mm (1.8M) Without the guns

• Length: 5000mm (5.0M)

• Weight: 1500KG

• Height: 2800MM (2.8M)

• Width: 2000mm (2.0M) Without the guns

• Length: 6500mm (6.5M)

• Weight: 3500KG

• Height: 3000MM (3.0M)

• Width: 2200mm (2.2M) Without the guns

• Length: 6000mm (6.0M)

• Weight: 4500KG
